SP-7XE/F Full-Rise Scissor Lift 49 P/N 5900010 — Rev. B3 — September 2023
Add the Drive-up Ramps: SP–7XE only
The SP-7XE includes four Drive-up Ramps: two per Frame. The SP-7XEF does not include Drive-up
Ramps, as it is flush mount.
You can attach the Drive-up Ramps in any configuration you want; they are all the same, so it does not
matter where you put them.
To put a Drive-up Ramp into position:
1. Put the pins over the slots in the Base, then move them down into the slots.
All four Ramps come with pins that fit into slots in the Base.
2. Double check to make sure they are correctly seated.
Final Checklist Before Operation
Make sure these things have been done before using your Lift:
3. Review the Installation Checklist to make sure all steps have been performed.
4. Make sure the Power Unit is receiving power from the power source.
5. Check the Hydraulic Fluid reservoir; it must be full of approved Hydraulic Fluid or automatic
transmission fluid. You can harm the motor by running it without enough fluid.
6. Check the Hydraulic System for leaks. Verify all Hydraulic Hoses connections, Hydraulic Fittings,
and Auxiliary Port Plugs on the Lift and Power Unit are tight.
7. Check to see that all Anchor Bolts are appropriately shimmed and correctly torqued.
8. Make sure that all Safety Locks are cleared and free.
Leave the Manual with the Owner/Operator
Make sure to leave the Installation and Operation Manual with the owner/operator so that it is available
for anyone who needs to read it.
