BJ250
13
LOCATION OF PARTS
1.TURNING INDICATOR
The indication lamps would ash with the turning signals.
2. GEAR INDICATOR LAMP
Numbers on the meter indicate the gear positions of the
vehicle including 1, 2, 3, 4, 5 and6.
3. TACHOMETER
Tachometer indicates the revolution per minute of engine.
4. NEUTRAL INDICATOR LAMP
When the transmission is in the neutral, the indicator lamp
would be on.
5. ODOMETER/ TRIP METER
Odometer records the total mileage driven, and Trip
meter can be reset, which records the mileages driven in
a specic period.
6. FUEL LEVEL WARNING LAMP
It indicates the fuel is less than 15% of total capacity in the
fuel tank.
7. FUEL LEVEL INDICATOR
It indicates the fuel level in the fuel tank.
8. HIGH BEAM INDICATOR LAMP
When the high beam lamp of the headlamp turns on, the
high beam indicator lamp would be on.
9. FUNCTION BUTTON A
Short press the button to switch between trip and odo-
meter functions on the meter. In “Trip”state,long press the
button to reset the "Trip" mileage.
10. FUNCTION BUTTON B
Short press the button to switch between km/h and mph.
11. SPEEDOMETER
Speedometer shows the running speed, kilometers/hours.
12. WATER TEMPERATURE WARNING LAMP
It should stop to check the water tank if the WARNING
LAMP is light.
13.ENGINE CONTROL SYSTEM TROUBLE INDI-
CATOR
Return to authorized dealer if this indicator is activated
during riding.
14. WATER TEMPERATURE INDICATOR
This indicator indicates the temperature of cooling liquid.
When the pointer is in between C and H, the temperature
is normal. It should stop to check the water tank if the
pointer is higher than H level.
