Beninca MARK - Page 32

32
AUX1
Selects the operating mode of output AUX1 (contact N.O.)
0: SCA (gate open indicator light) output. The indicator light is off with the gate closed,
flashing with the gate in motion and on with the gate open.
1: radio 2CH output The output is controlled by the second radio channel of the incorpo-
rated receiver (see RADIO menu).
2: courtesy light output (enabling time set by TLS parameter).
3: zone light output. The contact closes for the duration of the operation and for the dura-
tion of the TCA, opens again only when the gate is closed.
4: accessories power supply output (to check photocells - rib, combined with TST1-TST2-
TST3 logic)
5: flashing output
6: gate alarm exit open (gate open double for TCA time)
7: NC inputs alarm output or board error (NC=alarm not enabled, NO=alarm enabled)
0-7-(1)
* ATTENTION: FURTHER SETTING OF THESE PARAMETERS CAN BE DANGEROUS.
COMPLY WITH LEGISLATION IN FORCE!
LOGIC (LOG)
MENU FUNCTION
ON-OFF-(Default)
MEMO
TCA
Enables and disables automatic closure.
On: automatic closure enabled.
Off = automatic closure disabled
(OFF)
IbL
Enables or disables the shared function.
On: shared function enabled. The S.S. or transmitter impulse has no effect during the open-
ing phase.
Off: apartment complex function disabled.
(OFF)
IbCA
Enables or disables the PP controls during the TCA phase.
On: PP commands not enabled.
Off: PP commands enabled.
(OFF)
PP
Select the operating mode of the ”P.P. button” and the transmitter.
On: “Operation"; OPEN> CLOSE > OPEN>
Off: “Operation"; OPEN>STOP>CLOSE>STOP>
(OFF)
PRE
Enables or disables pre-flashing.
On: Pre-flashing enabled. The flashing light activates 3s before the motor starts.
Off: Pre-flashing disabled.
(OFF)
SCL
Enables and disables rapid closure.
On: rapid closure enabled. With the gate open or in the opening phase, intervention of the
photocell causes automatic closure 3 s.
Active only with TCA:ON
Off = rapid closure disabled
(OFF)
htr
Person present function enabled or disabled.
On: Person Present Operation
The OPEN/CLOSE button must be kept pressed throughout the manoeuvre.
Off: Automatic operation.
(OFF)
(OFF)
LTCA
Selection of the flashing light operating mode during the TCA time
On: Flashing indicator light on during TCA
Off: Flashing indicator light off during TCA
(OFF)
mbli
Selection of the flashing operating mode.
On: Flashing light 1 second On/ I sec Off (for flashing not equipped with intermittence)
Off: Fixed on flashing light (for flashing with intermittence)
(OFF)
TST1
Enables or disables checking the photocells on the PHOT A input (OPENING and CLOS-
ING).
On: Check enabled. If the check has a negative outcome, no manoeuvre is commanded.
See Fig.4.
Off: Test disabled.
(OFF)
TST2
It enables or disables checking the photocells on the PHOT C input (CLOSING).
On: Check enabled. If the check has a negative outcome, no manoeuvre is commanded.
See Fig.4.
Off: Test disabled.
(OFF)
