NUMBER OF MANOUEVRES (Nman)
It displays the number of complete cycles (open+close) carried out by automation. The first press of the <PG> button displays the first
4 digits, the second press displays the last 4. e.g. <PG> 0012 >>> <PG> 3456: executed 123.456 cycles.
MAINTENANCE CYCLES (maci)
This function allows you to enable the maintenance signal request after a number of manoeuvres established by the installation tech-
nician. To enable and select the number of manoeuvres, proceed as follows:
Press the <PG> button. The display shows OFF, which indicates the function is disabled (default value).
With the <+> and <-> buttons, select one of the numerical values proposed (from OFF to 100). The values should be intended as
hundreds of manoeuvre cycles (e.g.: the value 50 indicates 5000 manoeuvres). Press the OK button to enable the function. The dis-
play shows the message PROG. The maintenance request is signalled to the user while maintaining the flashing indicator light on for
another 10 s after conclusion of the opening or closure manoeuvre.
RESET (RES)
Control panel RESET CAUTION!: It returns the control panel to the default values.
Pressing the <PG> button for the first time causes the RES message to flash; pressing the <PG> button again resets the control
panel. Note: The transmitters are not deleted from the receiver or the access password.
All the logic and all the parameters are brought to the default values and it is therefore necessary to repeat the autoset procedure.
AUTOSET (AUTO)
Execute self-learning of automation stroke. See INSTALLATION paragraph.
PASSWORD DI ACCESSO (CODE)
It allows to type in an access protection code to the programming of the control unit.
A four-character alphanumeric code can be typed in by using the numbers from 0 to 9 and the letters A-B-C-D-E-F.
The default value is 0000 (four zeros) and shows the absence of a protection code.
While typing in the code, this operation can be cancelled at any moment by pressing keys + and – simultaneously. Once the password
is typed in, it is possible to act on the control unit by entering and exiting the programming mode for around 10 minutes in order to
allow adjustments and tests on functions.
By replacing the 0000 code with any other code, the protection of the control unit is enabled, thus preventing the access to any other
menu. If a protection code is to be typed in, proceed as follows:
- select the Code menu and press OK.
- the code 0000 is shown, also in the case a protection code has been previously typed in.
- the value of the flashing character can be changed with keys + and -.
- press OK to confirm the flashing character, then confirm the following one.
- after typing in the 4 characters, a confirmation message “CONF” appears.
- after a few seconds, the code 0000 appears again
- the previously stored protection code must be reconfirmed in order to avoid any accidental typing in.
If the code corresponds to the previous one, a confirmation message “OK” appears.
The control unit automatically exits the programming phase. To gain access to the Menus again, the stored protection code must be
typed in.
IMPORTANT: TAKE NOTE of the protection code and KEEP IT IN A SAFE PLACE for future maintenance operations.
To remove a code from a protected control unit it is necessary to enter into programming with the password and bring the
code back to the 0000 default value.
IF YOU LOOSE THE CODE, PLEASE CONTACT THE AUTHORISED SERVICE CENTER FOR THE TOTAL RESET OF THE CON-
TROL UNIT.
TRANSMITTERS REMOTE LEARNING
If you have a transmitter already stored in the receiver, it is possible to carry out radio remote learning (without having to access the
control panel).
IMPORTANT: The procedure must be carried out with the doors in opening during the TCA pause.
Proceed as follows:
1 Press the hidden key of the transmitter already stored.
2 Press, within 5s, the key of the transmitter already stored corresponding to the channel to associate with the new transmitter. The
flashing light comes on.
3 Press, within 10s, the hidden key of the new transmitter.
4 Press, within 5s, the key of the new transmitter to associate with the channel chosen in point 2. The flashing light goes out.
5 The receiver memorises the new transmitter and immediately exits programming.
