DSP 2500 Inverter System
10.15.07 10 028-0009-200
Frequency stability: 0.1% crystal controlled
Distortion factor: 2% at linear load
Permissible power factor: cos = 0.7 ind. to cos = 0.8 cap.
Efficiency at nominal real power: > 88 %
Internal output fuse: T30A/250V
Physical/Environmental
Weight: 30 lbs.
Permissible temperature range (non condensing): 0°C .... +40°C without derating
+41°C ... +55°C with linear derating of 100% to 60%
output at a rate of 2.5%P
N
/°C
(shutdown at +55°C, automatic restart at +53°C)
Cooling mode: Temperature controlled forced cooling, front to
back
Color: Black Textured Powder Coat Faceplate
Radio interference degree: B (EN 55022)
Protection Class: UL 1950
Input/Output Connections
DC Input: Two pole terminal block accepting a 2 hole lug,
5/8”cc, ¼” studs, 1 AWG Max
(2AWG to 2/0 possible with narrow tongue lug)
Frame Ground: 5/8”cc, ¼” studs, 1 AWG Max
(2AWG to 2/0 possible with narrow tongue lug)
120VAC Output Options: Three NEMA 5-15 output receptacles protected by a
15A push to reset circuit breaker
