DSP 2500 Inverter System
10.15.07 11 028-0009-200
Three NEMA Output receptacles protected by a 20A
push to reset circuit breaker
One 120VAC Bulk Terminal Block Output (L, N, G)
protected by a single-pole 30A rocker style breaker
Parallel Module Option: Dual RJ-45 receptacles and 120VAC Bulk Terminal
Block Input (L, N, and G) for parallel unit operation
Alarm: Potential free contact (NO, C, NC), issued when
Output AC is no longer present
Phoenix “Spring Clamp” style connector
Indicators
Optical Display: Output voltage present
Mains synchronized
Parallel module synchronized
Fault
Overload
Agency Approvals
Listed to UL 1950
