30 How to adjust your monitor
Working with two computers and one monitor
Working with two computers and two monitors
1. Establish cable connection as instructed in Connect the PC video cable on page 12.
2. Select KVM switch.
Working in PBP mode
Video source selection in PIP/PBP mode
Your monitor scans for the available video sources in the following order: HDMI, DP, and mini
DP, and displays the first available one. This video source will become the main source in
PIP/PBP mode. You will need to decide the second source for PIP/PBP mode from the menu in
PIP/PBP source on page 37. Menu options that are not available will become grayed out.
1. Establish cable connection as
instructed in Connect the PC
video cable on page 12.
2. Select an input source.
3. Select KVM switch.
1. Establish cable connection as
instructed in Connect the PC
video cable on page 12.
2. Enable PBP function from
Display > PIP/PBP >
Mode > PBP. See Video
source selection in PIP/PBP
mode on page 30 for more
information.
3. Select KVM switch.
PC 1 / PC 2
Video cable Video cable
PC 1 PC 2
Video cable Video cable
USB cable (type A to type B)
PC 1 PC 2
Video cable Video cable
