BenQ FP51G User Manual

15 Getting the most from your BenQ monitor
Should you wish to do so, this is where you can change the screen resolution (area and color).
See How to adjust the screen resolution for details.
14. Click OK.
This will close the Display Properties window, and if you made any changes to the screen resolution,
Windows 2000 will prompt you for confirmation to effect the changes, and further confirmation to
accept the changes. Click OK and Ye s respectively.
Alternatively, Windows ME or 98 will ask you if want to make the changes and reboot or not reboot.
You should select the reboot option as this causes Windows to load the new drivers when it next
restarts.

BenQ FP51G Specifications

Panel Specifications

LCD Size	15.0"
Display Area	304.1 x 228.1 mm
Pixel Pitch	0.297 mm
Brightness	250 cd/m2
Contrast Ratio	400:1
Viewing Angle	120/100 (L/R;U/D, CR>=10)
Response Time	12 ms
Display Colors	16.2 million

Monitor Specifications

Resolution	1024 x 768 (XGA)
Horizontal Frequency	31 - 63 KHz
Vertical Frequency	56 - 75 Hz
Video Bandwidth	25 - 80 MHz
Input Connector	D-Sub
Power Supply	90~264 AC, Built-in
Power Consumption (On mode)	30 W (max)
Power Consumption (Power saving mode)	1 W/120V, 2 W/240V

Weight and Dimensions

Net Weight	8.2 Lbs
Gross Weight	10.1 Lbs
Dimensions	338 x 331 x 136 mm
CTN Dimensions	395 x 380 x 120 mm
