BenQ FP51G User Manual

17 How to adjust the screen refresh rate
How to adjust the screen refresh rate
You don’t have to choose the highest possible refresh rate on an LCD display, because it is not
technically possible for an LCD display to flicker. The best results are obtained by using the
factory modes already set in your computer. There is a table with the factory modes in the
specification section of this User’s Manual.
You can choose 60, 70 and 75 Hertz, (but not 72Hz) for the native resolution of 1024x768.
1. Double click the Display icon in Control Panel.
2. From the Display Properties window, select the Settings tab and click the Advanced button.
3. Select the Adapter tab, and select an appropriate refresh rate to match one of the applicable
factory modes as listed in the specification table.
4. Click Change, OK, then Ye s .
5. Close the Display Properties window.
1
1
1
6

BenQ FP51G Specifications

Panel Specifications

LCD Size	15.0"
Display Area	304.1 x 228.1 mm
Pixel Pitch	0.297 mm
Brightness	250 cd/m2
Contrast Ratio	400:1
Viewing Angle	120/100 (L/R;U/D, CR>=10)
Response Time	12 ms
Display Colors	16.2 million

Monitor Specifications

Resolution	1024 x 768 (XGA)
Horizontal Frequency	31 - 63 KHz
Vertical Frequency	56 - 75 Hz
Video Bandwidth	25 - 80 MHz
Input Connector	D-Sub
Power Supply	90~264 AC, Built-in
Power Consumption (On mode)	30 W (max)
Power Consumption (Power saving mode)	1 W/120V, 2 W/240V

Weight and Dimensions

Net Weight	8.2 Lbs
Gross Weight	10.1 Lbs
Dimensions	338 x 331 x 136 mm
CTN Dimensions	395 x 380 x 120 mm
