BenQ FP51G User Manual

30 Specifications
Specifications
BenQ FP51G
1
1
1
11
Model FP51G
Display type
Viewable diagonal
Native (maximum) resolution
Colors
Contrast / Brightness
Response time
Viewing angle (left/right, up/down)
15.0" , active, TFT
38.1 cm
1,024 x 768
16.2 million
400:1 / 250 cd/m
2
12 ms
120, 100 (CR=10)
150, 125 (CR=5)
Line frequency
Image frequency
31 - 63 kHz Multi- frequency monitor
56 - 75 Hz modes within these parameters
Image checks
Controls
Functions
Digital, Screen OSD Technology, iKey
(automatic image setting)
5 buttons and iKey.
Contrast, brightness, vert. & hor. image position,
phase, pixel clock, color balance, color palette,
choice of language (8 language OSD), OSD
position, status indicator
Power Management
Max. power consumption
Power saving mode
VESA DPMS, EPA
30 Watt
< 1 Watt
Input signal
Synchronisation
RGB analog 0.7 Vpp/75 Ohm positive
TTL separate signal connection 15-pin mini D-sub
cable
Temperature (operating)
Air humidity (operating)
0 °C - 40 °C
10% - 90%
Certifications TCO 99/03, TÜV/Ergonomics, TÜV/ GS, FCC
Class B, ISO 13406-2, VCCI, CB Report, CE,
C-Tick, BSMI, Fimko, GOST, CSAUS, CCC
Operating voltage
Dimensions (H x W x D)
Weight
Automatic switched mode power supply,
90-264 V, 47-63 Hz
338 x 331 x 136 mm
3.7 kg

BenQ FP51G Specifications

Panel Specifications

LCD Size	15.0"
Display Area	304.1 x 228.1 mm
Pixel Pitch	0.297 mm
Brightness	250 cd/m2
Contrast Ratio	400:1
Viewing Angle	120/100 (L/R;U/D, CR>=10)
Response Time	12 ms
Display Colors	16.2 million

Monitor Specifications

Resolution	1024 x 768 (XGA)
Horizontal Frequency	31 - 63 KHz
Vertical Frequency	56 - 75 Hz
Video Bandwidth	25 - 80 MHz
Input Connector	D-Sub
Power Supply	90~264 AC, Built-in
Power Consumption (On mode)	30 W (max)
Power Consumption (Power saving mode)	1 W/120V, 2 W/240V

Weight and Dimensions

Net Weight	8.2 Lbs
Gross Weight	10.1 Lbs
Dimensions	338 x 331 x 136 mm
CTN Dimensions	395 x 380 x 120 mm
