BenQ FP51G User Manual

16 How to adjust the screen resolution
How to adjust the screen resolution
Due to the nature of liquid crystal display (LCD) technology, the picture resolution is always
fixed. The best possible picture for your FP51G is achieved with a resolution of 1024 x 768. This is
called “Native Resolution” or maximal resolution – that is, the clearest picture. Lower resolutions
are displayed on a full screen through an interpolation circuit. However flaws do occur with the
interpolated resolution.
To take full advantage of LCD technology you should select the native resolution setting
of 1024x768.
1. Open Display Properties and select the Settings tab.
You c a n o p e n Display Properties by right-clicking on the Windows desktop and selecting Properties
from the pop-up menu.
2. Use the slider in the ‘Screen area’ section to adjust the screen resolution.
Select the recommended resolution of 1024 x 768 then click Apply.
If you select some other resolution, be aware that this other resolution is interpolated and
may not accurately display the screen image as well as it could do at the native resolution
setting.
3. Click OK then Ye s .
4. Close the Display Properties window.
1
1
1
5

BenQ FP51G Specifications

Panel Specifications

LCD Size	15.0"
Display Area	304.1 x 228.1 mm
Pixel Pitch	0.297 mm
Brightness	250 cd/m2
Contrast Ratio	400:1
Viewing Angle	120/100 (L/R;U/D, CR>=10)
Response Time	12 ms
Display Colors	16.2 million

Monitor Specifications

Resolution	1024 x 768 (XGA)
Horizontal Frequency	31 - 63 KHz
Vertical Frequency	56 - 75 Hz
Video Bandwidth	25 - 80 MHz
Input Connector	D-Sub
Power Supply	90~264 AC, Built-in
Power Consumption (On mode)	30 W (max)
Power Consumption (Power saving mode)	1 W/120V, 2 W/240V

Weight and Dimensions

Net Weight	8.2 Lbs
Gross Weight	10.1 Lbs
Dimensions	338 x 331 x 136 mm
CTN Dimensions	395 x 380 x 120 mm
