BenQ FP93G User Manual

22 How to adjust the screen refresh rate
How to adjust the screen refresh rate
You don’t have to choose the highest possible refresh rate on an LCD display, because it is not
technically possible for an LCD display to flicker. The best results are obtained by using the
factory modes already set in your computer. There is a table with the factory modes in the
specification section of this User’s Manual.
You can choose 60, 70 and 75 Hertz, (but not 72Hz) for the native resolution of 1280x1024.
1. Double click the Display icon in Control Panel.
2. From the Display Properties window, select the Settings tab and click the Advanced button.
3. Select the Adapter tab, and select an appropriate refresh rate to match one of the applicable
factory modes as listed in the specification table.
4. Click Change, OK, then Ye s .
5. Close the Display Properties window.
1
1
1
6
Downloaded from ManualMonitor.com Manuals

BenQ FP93G Specifications

Panel Specifications

LCD size	19.0"
display area	376.3 x 301.1 mm
pixel pitch	0.294 mm
brightness	300 cd/m²
contrast	700:1
viewing angle	140/135
response time	6 ms
display colors	16.2 million

Monitor Specifications

resolution	1280 x 1024 (SXGA)
horizontal frequency	31 - 81 KHz
vertical frequency	60 - 76 Hz
video bandwidth	25 - 135 MHz
input connector	D-sub, DVI
power consumption (on mode)	40 W (max)
power consumption (power saving mode)	1W/120V, 2W/240V

Dimensions and Weight

dimensions	410 x 404.2 x 168.2 mm
net weight	11.0 lbs
gross weight	14.3 lbs
