BenQ FP93G User Manual

37 Specifications
Specifications
BenQ FP93G
1
1
1
11
Model FP93G
Display type
Viewable diagonal
Native (maximum) resolution
Colors
Contrast / Brightness
Response time
Viewing angle (left/right, up/down)
19.0”, active, TFT
480 mm
1,280 x 1,024
16.2 million
700:1 / 300 cd/m
2
6 ms
140, 135 (CR=10)
160, 160 (CR=5)
Line frequency
Image frequency
31 - 81 kHz Multi- frequency monitor
56 - 76 Hz modes within these parameters
Image diagnostics
Controls
Functions
Digital, OSD Technology, i Key (automatic image
setting)
5 buttons and i Key.
Contrast, brightness, vert. & hor. image position,
phase, pixel clock, color balance, color palette,
multiple-language OSD, OSD position, status
indicator, input selection
Power management
Max. power consumption
Power saving mode
VESA DPMS, EPA
40 Watt
< 1 Watt, 120 V
< 2 Watt, 240 V
Input signal
Synchronization
RGB analog 0.7 Vpp/75 Ohm positive
Digital: DVI-D (optional)
TTL separate signal connection 15-pin mini D-sub
cable
Temperature (operating)
Air humidity (operating)
0 °C - 40 °C
10% - 90%
Certifications TCO 03, TÜV/Ergonomics, TÜV/ GS, FCC Class
B, ISO 13406-2, VCCI, CB Report, CE, C-Tick,
BSMI, Fimko, GOST, CSA, CCC
Downloaded from ManualMonitor.com Manuals

BenQ FP93G Specifications

Panel Specifications

LCD size	19.0"
display area	376.3 x 301.1 mm
pixel pitch	0.294 mm
brightness	300 cd/m²
contrast	700:1
viewing angle	140/135
response time	6 ms
display colors	16.2 million

Monitor Specifications

resolution	1280 x 1024 (SXGA)
horizontal frequency	31 - 81 KHz
vertical frequency	60 - 76 Hz
video bandwidth	25 - 135 MHz
input connector	D-sub, DVI
power consumption (on mode)	40 W (max)
power consumption (power saving mode)	1W/120V, 2W/240V

Dimensions and Weight

dimensions	410 x 404.2 x 168.2 mm
net weight	11.0 lbs
gross weight	14.3 lbs
