BenQ FP93G User Manual

24 How to adjust your monitor
How to adjust your monitor
A Look at the Control Panel
There are 6 keys for user’s control including “ iKey ”, “Exit”, “Enter”, “<” and “>” key and a power
switch. The following descriptions are the introduction of these keys & switch.
1. “ iKey ”: Adjust vertical position, phase, horizontal position and pixel clock automatically.
2. “Exit” key: Back to previous menu or exit OSD. This key is also the hot key for Input Select.
3. W (Left) key: For Left/Decrease adjustment. Left key is the hot key for Contrast.
4. X (Right) key: For Right/Increase adjustment. Right key is the hot key for Brightness.
5. “Enter” key: Activate OSD, enter sub menu, select items, and confirm selection.
6. “Power”: Turn the power on or off.
1
1
1
8
Downloaded from ManualMonitor.com Manuals

BenQ FP93G Specifications

Panel Specifications

LCD size	19.0"
display area	376.3 x 301.1 mm
pixel pitch	0.294 mm
brightness	300 cd/m²
contrast	700:1
viewing angle	140/135
response time	6 ms
display colors	16.2 million

Monitor Specifications

resolution	1280 x 1024 (SXGA)
horizontal frequency	31 - 81 KHz
vertical frequency	60 - 76 Hz
video bandwidth	25 - 135 MHz
input connector	D-sub, DVI
power consumption (on mode)	40 W (max)
power consumption (power saving mode)	1W/120V, 2W/240V

Dimensions and Weight

dimensions	410 x 404.2 x 168.2 mm
net weight	11.0 lbs
gross weight	14.3 lbs
