BenQ FP93G User Manual

25 How to adjust your monitor
Hot Key Mode
Brightness hot key and Contrast hot key
Input Select hot key
Main Menu Mode
Control Functions Available in Main Menu
Press the X key to enter the Brightness menu.
Further press the W or X keys to adjust the
degree of screen brightness and press the Exit
key to exit OSD.
Press the W key to enter the Contrast menu.
Further press the W or X keys to adjust the
degree of screen contrast and press the Exit key
to exit OSD.
Press the Exit key to enter the Input Select
menu.
Further press the W or X keys to indicate the
input source and press the Enter key. When
done, press the Exit key to exit OSD.
Main Menu
Downloaded from ManualMonitor.com Manuals

BenQ FP93G Specifications

Panel Specifications

LCD size	19.0"
display area	376.3 x 301.1 mm
pixel pitch	0.294 mm
brightness	300 cd/m²
contrast	700:1
viewing angle	140/135
response time	6 ms
display colors	16.2 million

Monitor Specifications

resolution	1280 x 1024 (SXGA)
horizontal frequency	31 - 81 KHz
vertical frequency	60 - 76 Hz
video bandwidth	25 - 135 MHz
input connector	D-sub, DVI
power consumption (on mode)	40 W (max)
power consumption (power saving mode)	1W/120V, 2W/240V

Dimensions and Weight

dimensions	410 x 404.2 x 168.2 mm
net weight	11.0 lbs
gross weight	14.3 lbs
