BenQ G2200W User Manual

8 How to assemble your monitor hardware
2. Connect the PC video cable.
Do not use both DVI-D cable and D-Sub cable on the
same PC. The only case in which both cables can be
used is if they are connected to two different PCs with
appropriate video systems. (Not available for analog-only
models)
Connect one end of the DVI-D cable to the monitor
DVI-D socket and the other end to the DVI-D port on
your computer. (optional, not available for analog-only
models)
The DVI-D format is used for direct digital connection
between source video and digital LCD monitors or
projectors. The digital video signals produce a superior
quality picture than analog video signals.
Connect the plug of the D-Sub cable (at the end without
the ferrite filter) to the monitor D-Sub socket. Connect the
other plug of the D-Sub cable (at the end with the ferrite
filter) to the computer video D-Sub socket.
Tighten all finger screws to prevent the plugs from acci-
dently falling out during use.
Either
Or
3. Connect the power cable to the monitor.
Plug one end of the power cord into the socket labelled
‘POWER IN’ on the rear of the monitor. Do not connect
the other end to a power outlet just yet.
Downloaded from ManualMonitor.com Manuals

BenQ G2200W Specifications

General

Display diagonal	22 \
Separate H/V sync	No
Display resolution	1680 x 1050 pixels
Contrast ratio (dynamic)	2500:1
Contrast ratio (typical)	1000:1
Digital vertical frequency	55 - 76 Hz
Digital horizontal frequency	31 - 83 kHz
Display brightness (typical)	300 cd/m²
Video in	DVI-D, D-Sub
Ethernet LAN (RJ-45) ports	0
HDCP	Yes
Certification	TCO'03
Product color	Black
Market positioning	-
Bundled software	Driver CD
Power consumption (typical)	45 W
Power consumption (PowerSave)	2 W
Sustainability certificates	ENERGY STAR
LED indicators	Stand-by

Weight and Dimensions

Depth (with stand)	163.4 mm
Width (with stand)	401.6 mm
Height (with stand)	512.2 mm
Weight (without stand)	5300 g
