BenQ G900WA User Manual

19” LCD Color Monitor BenQ G900WA
2
1. About This Manual
This Service Manual is issued by engineer of TPV customer service according to the structure and capability
of various models. The purpose of Service Manual is to provide a guide line to engineers to repair different
models. The appearance and capability is introduced in this Service Manual. It is better for repair engineer to
have a rough idea of this model through reading the Service Manual. Please do pay attention to the item part of
THE DISASSEMBLY when repair the machine and also do the protection of Panel any time. When repairing the
circuit board, please follow the requirement of RoHS and refer to the circuit diagram and repairing process that
attached in the Service Manual. The method of firmware updated, the way of using the menu and some
information that may be used when repairing are also attached in the Service Manual that provide repair
engineer various choice.
If you have any questions, please contact with the engineers of TPV customer service.
COLOR MONITOR
MODEL ID G900WA (EU)
1st Edition
July 2007

BenQ G900WA Specifications

General

Pixel pitch	0.283 x 0.283 mm
Display diagonal	19 \
Display resolution	1400 x 900 pixels
Vertical scan range	55 - 76 Hz
Horizontal scan range	31 - 83 kHz
Contrast ratio (typical)	800:1
Viewing angle, horizontal	160 °
Display brightness (typical)	300 cd/m²
Bandwidth	0.135 GHz
Display viewable area (HxV)	408.2 x 255.1 mm
Cable lock slot	Yes
Tilt angle range	-5 - 20 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Power consumption (typical)	40 W
Sustainability certificates	ENERGY STAR
Safety	TCO'03
Market positioning	-

Weight and Dimensions

Depth (without stand)	365.7 mm
Width (without stand)	441.3 mm
Height (without stand)	165 mm
Weight (without stand)	3730 g
