89
Appendix 1 – Screw List / Torque
Part No. Type Description Quantity Torque
0Q1G 930 8120 Q3*8 HINGE & HINGE BKT & REAR COVER 1
0M1G1740 10 47 CR3 M4*10 HIGNE & REAR COVER 4 12 ± 2kgf.cm
0M1G1740 8 47 CR3 M4*8 HINGE & STAND 3
0D1G1030 6120 D3*6 MAIN/POWER BOARD & MAINFRAME 6 6 ± 1kgf.cm
0M1G1740 6120 M4*6 POWER BOARD & MAINFRAME 1 6 ± 1kgf.cm
