Maintenance 45
4. Disconnect the lamp connector from the
projector.
5. Loosen the screw that secures the lamp.
6. Pull the lamp from the projector.
• Pulling it too quickly may cause the lamp to break
and scatter broken glass in the projector.
• Do not place the lamp in locations where water
might splash on it, children can reach it, or near
flammable materials.
• Do not insert your hands into the projector after
the lamp is removed. If you touch the optical
components inside, it could cause color
unevenness and distortion of the projected
images.
7. As shown in the figure, hold the new lamp and
align the two locators on the lamp with the
holes on the projector, and then pull the lamp
all the way into the projector.
8. Connect the lamp connector to the projector.
