What to do if my BenQ Digital projector does not turn on?
If your BenQ Digital projector doesn't turn on, ensure the power cord is properly plugged into both the projector's AC inlet and a functioning power outlet. If the outlet has a switch, make sure it's on. Also, if the projector is cooling down, wait until the process is complete before attempting to turn it on again.
How to fix a BenQ Digital projector with no picture?
If your BenQ Digital projector shows no picture, first, ensure that the video source is turned on and correctly connected. Check the connection between the projector and the input signal device. Then, select the correct input signal using the SOURCE key on the projector or remote control.
Why is my BenQ Digital projector image blurred?
If your BenQ Digital projector image is blurred, adjust the focus of the lens using the focus ring. Also, adjust the projection angle, direction, and height of the unit to properly align the projector and the screen.
What to do if BenQ Digital projector remote control does not work?
If your BenQ Digital projector remote control isn't working, replace the battery with a new one. Ensure there are no obstacles between the remote control and the projector. Also, make sure you are standing within 8 meters (26 feet) of the projector.
General| Native aspect ratio | 4:3 |
|---|---|
| Projection distance | - m |
| Vertical scan range | 23 - 120 Hz |
| Horizontal scan range | 15 - 102 kHz |
| Projection technology | DLP |
| Contrast ratio (typical) | 15000:1 |
| Screen size compatibility | 60 - 300 \ |
| Projector native resolution | SVGA (800x600) |
| Vertical synchronization (max) | 0.12 kHz |
| Vertical synchronization (min) | 0.023 kHz |
| Horizontal synchronization (max) | 102 kHz |
| Horizontal synchronization (min) | 15 kHz |
| RMS rated power | 2 W |
| Number of built-in speakers | 1 |
| Offset | 106 % |
| Throw ratio | 1.94 - 2.32 |
| Focal length range | 21.8 - 25.6 mm |
| Aperture range (F-F) | 2.46 - 2.66 |
| Placement | Desktop |
| Product type | Standard throw projector |
| Product color | White |
| Cable lock slot type | Kensington |
| Full HD | No |
| Supported 3D formats | Frame Sequential, Frame packing, Side by side, Top and bottom |
| Supported video modes | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
| Analog signal format system | NTSC, PAL, SECAM |
| Supported graphics resolutions | 640 x 480 (VGA), 1920 x 1200 (WUXGA) |
| Lamp type | UHP |
| Lamp power | 203 W |
| Light source type | Lamp |
| Service life of light source | 4500 h |
| Service life of light source (economic mode) | 10000 h |
| Power source | AC |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (max) | 260 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (typical) | 252 W |
| Power consumption (PowerSave) | 211 W |
| Serial interface type | RS-232 |
| USB 2.0 ports quantity | USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them. |
| Component video (YPbPr/YCbCr) in | 0 |
| Noise level | 32 dB |
| Noise level (economic mode) | 29 dB |
| On Screen Display (OSD) languages | ARA, BUL, CHI (SIMPL), CHI (TR), CRO, CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HIN, HUN, IND, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, THA, TUR |
| Remote control type | IR |
Weight and Dimensions| Depth | 241.3 mm |
|---|---|
| Width | 332.4 mm |
| Height | 99 mm |
| Weight | 2380 g |
Essential safety guidelines for operating the projector safely.
Explains the buttons and indicators on the projector's body.
Details the operation and purpose of each button on the remote control.
Illustrates various cables and ports for connecting signal sources to the projector.
Instructions for connecting PCs and notebooks via VGA or HDMI.
Details connections for HDMI, Component Video, S-Video, and standard Video.
Detailed steps for powering on the projector and initial setup.
How to adjust the projector's angle and feet for optimal image placement.
Using the AUTO function to optimize picture quality automatically.
Adjusting zoom and focus for optimal image dimensions and sharpness.
Methods for fixing trapezoidal distortion using remote or OSD menus.
Detailed adjustments for brightness, contrast, color, tint, sharpness, and brilliant color.
Explains the structure and navigation of the On-Screen Display (OSD) menus.
How to use a security cable and set up a projector password for protection.
Choosing predefined modes (Bright, Cinema, etc.) for optimal viewing.
Explains the structure and navigation of the On-Screen Display (OSD) menus.
Detailed settings for Picture Mode, Brightness, Contrast, Color, etc.
Details on Wall Color, Aspect Ratio, Keystone, Position, Phase, H. Size, Digital Zoom.
Instructions for cleaning the lens and projector case.
How the projector calculates and displays lamp usage time.
Resolving issues related to power supply and startup.
Diagnosing and fixing display issues like no signal or image focus.
Troubleshooting remote control functionality and forgotten passwords.
Detailed specifications for resolution, lens, power supply, and consumption.
