7. Output Functional specification
A
ll the tests to verify specifications in this section must be performed under the following standard
conditions unless otherwise noted. The standard conditions are:
-Temperature: 15- 25degree Celsius
-AC line input voltage: 110~240VAC
-Checking display mode: All the presenting modes.
-Warm-up time: 30 minutes minimum
8. Display Quality
Display Performance:
Item
Parameter Specification
1 Display pixels 1920*R.G.B.*1080
2 Display cells NA
3 Pixel pitch 271.5(H)um*271.5(V) um
4 Cell pitch NA
5 Display pixel type NA
6 Active Area 521.28(H)mm*293.22(V)mm
7
Brightness
(cd/m2)
Min
Typ
Ma
Center 250
300
-
Average - -
-
8 White variation - - 1.3
9 Contrast ratio 700 1000 -
Color
Chromaticity
Red
Rx
0.617 0.647 0.677
Ry
0.304 0.334 0.364
Green
Gx
0.254 0.284 0.314
Gy
0.577 0.607 0.637
Blue
Bx
0.121 0.151 0.181
By
0.041 0.071 0.101
White
W
x
0.283 0.313 0.343
W
y
0.299
0.329
0.359
Color Gamunt 70% 72% -
View Angle
CR=10
85(H)
-85(H)
80(V)
-80(V)
-
