Appendix 1 – Screw List /Torque
ITEM DESCRIPTION SPECIFICATION Q‘TY
TORQUE
(KG-CM)
WHERE USE Q‘TY
1
SCREW SPE
ISZZTER001A M3*6L
MSWR17/FZMYI
14
5~6Kgf/cm Power board to metal fittg 6
ISZZTER001A M3*6L
MSWR17/FZMYI
5~6Kgf/cm Ground plate to metal fittg 2
ISZZTER001A M3*6L
MSWR17/FZMYI
5~7Kgf/cm mainboard to metal fittg 4
ISZZTER001A M3*6L
MSWR17/FZMYI
5~6Kgf/cm TUNER CON/B to tuner box bracket 2
2
SCREW SPE
STAND-OFF HEX #4-40UNC
H5*5*7L
2 5~7Kgf/cm Lock up to VGA connector 2
3
SCREW M3*5MM 4 4~6Kgf/cm Metal fittg to panel 4
4
SCREW
M3X6 P=0.5
9
5~7Kgf/cm Tuner box bracket to metal fittg 4
M3X6 P=0.5 5~7Kgf/cm Lock up to HDMI connector 1
M3X6 P=0.5 5~6Kgf/cm Bracket fix to metal fittg 2
M3X6 P=0.5 5~6Kgf/cm I/O cover to metal fittg 2
5
SCREW M3*6 P=0.5 BLACK 5 5~6Kgf/cm Lock up to back cover 5
6
SCREW M3X8 P=0.5 BLACK 1 5~6Kgf/cm Lock up to I/O cover 1
7
SCREW FMS+ M3*6 ZN-BLACK 1 5~6Kgf/cm Lock up to back cover 1
8
SCREW BND T+
M3X8(BND T+)
7
4~6Kgf/cm Keypad to front bezel 2
M3X8(BND T+) 5~7Kgf/cm Metal fittg to front bezel 2
M3X8(BND T+) 5~7Kgf/cm Lock up to AV connector 3
9
SCREW BND T+ M4X10(BND T+) 4 6~8Kgf/cm Metal fittg to front bezel 4
10
SCREW BND T+ M4X10(BND T+) (BLK) 4 6~8Kgf/cm Lock up to back cover 4
11
SCREW BND T+ M4X16(BND T+) 4 8~10Kgf/cm Hinge to arm 4
12
SCREW P SW+ M4*12 PSW+ 4 8~10Kgf/cm Hinge to bracket fix 4
