25
(9) Maintainability Specifications
1. General & Requirements
(1) Main Board ASSY
(2) Keypad Board ASSY
(3) IR Board ASSY
(4) Power Board ASSY
2. Mean Time to Repair
2.1 Module Level:
Less than 20 minutes
2.2 Component Level:
Less than 20 minutes
3. Equipment & Tools Required
3.1 Standard Test Equipment:
Test Equipment Manufacturer/ Model # /Version
Video Signal Generator CHROMA 2135 Pattern Generator, Fluke 54200
Audio Signal Generator Panasonic Audio Analyzer VP-7723A, Fluke 54200
RF Signal Generator Fluke 54200
Head Phone Sony Mini-Plug Headset
DVD Player SAMPO DVD Player DV-F46
VC
R
SAMPO VC-360
Audio Test Pattern
“Video Essential” DVD, Fluke 54200 Generator
built-in
Video Test Pattern
“Video Essential” DVD, Fluke 54200 generator
built-in video pattern
Host PC LEMEL with Win2000
LCD Color Analyzer Minolta CA210
Digital Real-time Oscilloscope Tektroni
x
Screen Performance Test for RGB “Display-Mate” program for Host PC
