1. 1. Test content
KEY Test Condition TEST ITEM Input Equipment
PC Mode
EDID ‘s software Check EDID
D-SUB
PC
Audio
PC&
Chroma23291
or Chroma2329
or MIK K-8257
Adjust volume from min to max,
adjust Balance
PC sound check
Follow Engineering spec ‘s timing
1.check if video is
normal
2.check noise
Full W , R, G, B Dots check
HDTV
HDTV 720P Picture quality
Ypbpr
Chroma 29231 or
Chroma 2329
or MIK K-8257
HDTV 480P Picture quality
HDTV 1080i Picture quality
SDTV 576i Picture quality
HDMI
HD 480i Picture quality
HDMI Chroma 23291
or Chroma2329
HD 480P Picture quality
HD 720P Picture quality
HD 1080i Picture quality
KEY Test Condition TEST ITEM Input Equipment
DVD
NTSC disk Picture quality
Ypbpr&
AV & S V
&HDMI
DVD PAL disk Picture quality
L-R Balance check Sound quality
TV tuner
Use PAL B/G system
Nicam stereo or Nicam Mono
Contrast TV channel list choice 2
Frequency
1.
V
ertical color bar
2. Mono Scope
3. Multi –Burst
4. Auto Scan
5. Stereo & Mono
sound
ANT
Shibasoku
TG19C
Use PAL D/K system
Nicam Dual or FM Mono
Contrast TV channel list choice 2
Frequency
6.
V
ertical color bar
7. Mono Scope
8. Multi –Burst
9. Auto Scan
Stereo & Mono sound
Use PAL I system
FM Mono Contrast TV
channel list choice 2 Frequency
10.
V
ertical color bar
11. Mono Scope
12. Multi –Burst
13. Auto Scan
Stereo & Mono sound
 The Contrast table of Fluke program and TV channel
