BenQ MK2432 - Page 50

50
EXPLODED VIEW PARTS LIST
Ref. No. Source DESCRIPTION SPECIFICATION Q‘TY REMARK
1F01 FRONT BEZEL
JC240B ABS 94HB G.L BLACK C FOR BENQ(HDMI
HDTV)(MK2432)
1
1F02 LED INDIC.-PWR JC236B UT-0520T COLOR T57015 1
1F03 IR COVER JC236B PC GE-121R-21051 1
1F04 FUNCTION KEY JC229A ABS 94HB BLACK C 1
1F05 NAME PLATE 26x7.4mm Material Sticker BenQ 1
1F08 SCREW BND T+ M3X8(BND T+) 3
2C01 CABI BACK JC240A ABS 94HB BLACK C (TAIWAN)(ENGLISH) 1
2C02 BRACKET FIX JT198QP SECC 0.8T WALL MOUNT 1
5B01 NECK JC236A ABS 94HB BLACK C 1
5B02 HINGE N2430P SECC T=2.0°~20° 50KG-CM 1
5B03 SCREW P SW+ M4*12 PSW+ 4
5B04 STAND JT229HP J-STAND ABS HB (G.L BLACK/MT11010) 1
5B05 SCREW BND T+ M4X16(BND T+) 4
5B06 FOOT PAD
φ20*3.0T SQUARE GRAIN BLK
4
5F01 METAL FITTG JC236 PANEL SECC T=0.6mm TAIWAN 1
5F02 SCREW M3*5MM 4
5F03 SCREW BND T+ M3X8(BND T+) 2
5F04 SCREW BND T+ M4X10(BND T+) 4
5F05 SCREW SPE ISZZTER001A M3*6L MSWR17/FZMYI 6
5F06 SCREW M3X6 P=0.5 4
5F07 SCREW SPE ISZZTER001A M3*6L MSWR17/FZMYI 2
5F08 BRACKET FIX SE2221 TUNER BOX BKT SECC 0.6T 1
5F09 SCREW SPE ISZZTER001A M3*6L MSWR17/FZMYI 4
5F10 SHIELD PLATE JC236 SPTE T=0.3 TAIWAN 1
5F11 SCREW BND T+ M3X8(BND T+) 3
5F12 SCREW M3X6 P=0.5 1
5F13 SCREW SPE STAND-OFF HEX #4-40UNC H5*5*7L 2
5F14 BRACKET FIX N2430P FOR HINGE T=1.0mm 1
5F15 SCREW M3X6 P=0.5 2
5F16 SCREW SPE ISZZTER001A M3*6L MSWR17/FZMYI 2
5F17 METAL FITTG-I/O JC240A&B IO-SIDE SECC 0.3T (TAIWAN) 1
5F18 DUST COVER VT2430 ABS 94HB BLACK C IO-SIDE COVER (TAIWAN) 1
5F19 DUST COVER VT2430 ABS 94HB BLACK C TUNNER BOX COVER 1
5F20 SCREW M3X6 P=0.5 2
5F21 SCREW M3X8 P=0.5 BLACK 1
5F25 SPONGE SPONGE BLACK 20*15*50MM 1
6B01 SCREW BND T+ M4X10(BND T+) (BLK) 4
6B03 SCREW M3*6 P=0.5 BLACK 5
6B04 DUST COVER N2430P ABS 94HB BLACK C 1
6B05 SCREW FMS+ M3*6 ZN-BLACK 1
