Operation46
Description of each menu
• The default values listed in this manual, especially on pages 46-54, are for reference only.
They may vary between the projectors due to the continuous improvement to the
products.
FUNCTION
(default setting/
value)
DESCRIPTION (default setting/value)
Wall Color
Corrects the projected picture’s color when the projection surface is
not white. See "Using Wall Color" on page 35 for details.
Aspect Ratio
There are four options to set the image's aspect ratio depending on
your input signal source. See "Selecting the aspect ratio" on page 32 for
details.
Keystone
Corrects any keystoning of the image. See "Magnifying and searching
for details" on page 32 for details.
Position
Displays the position adjustment page. To move the projected image,
use the directional arrow keys. The values shown on the lower position
of the page change with every key press you made until they reach
their maximum or minimum.
This function is only available when a PC signal (analog RGB) is
selected.
Phase
(depends on the
selected input
signal)
Adjusts the clock phase to reduce image
distortion.
This function is only available when a PC
signal (analog RGB) is selected.
H. Size
Adjusts the horizontal width of the image.
This function is only available when a PC signal (analog RGB) is
selected.
Digital Zoom
Magnifies or reduces the projected image. See "Magnifying and
searching for details" on page 32 for details.
1. DISPLAY menu
