Connection 17
Connection
When connecting a signal source to the projector, be sure to:
1. Turn all equipment off before making any connections.
2. Use the correct signal cables for each source.
3. Ensure the cables are firmly inserted.
• In the connections shown below, some cables may not be included with the projector (see
"Shipping contents" on page 8). They are commercially available from electronics stores.
• For detailed connection methods, see pages 17-24.
1. Audio cable 6. Component Video to VGA (DSub)
adapter cable
2. VGA cable 7. S-Video cable
3. VGA to DVI-A cable 8. Video cable
4. Type B to type A USB cable 9. HDMI cable
5. Mini-B to type A USB cable 10. USB flash drive/wireless dongle
6
7
9
1
1
2
4
8
3
2
10
1
5
To Next Page
