BenQ MX823ST - Wall Mount Installation Requirements

Specifications 59
Wall mount installation
Minimum installation requirements
Computer
Resolution:
XGA
Resolution:
XGA
Diagram
Reference
SMART
Board
660
Smart
Board
680
Promethean
ActivBoard
164
Promethean
ActivBoard
178
RM
ClassBoard2
77.5
Hitachi
StarBoard
FX-63
StarBoard
FX-77
Diagonal
(inches)
D647764 78 78 63 77
Height
(mm)
H 975 1173 975 1189 1181 960 1173
Width
(mm)
W 1300 1565 1300 1585 1575 1280 1565
Distance
from floor
to bottom
of image
(mm)
f 900 900 900 900 900 900 900
Distance
from
screen
surface to
projector
rear case
(mm)
a 790 950 790 970 970 780 950
Distance
from top
case to the
top of
(mm)
b 94 124 94 126 126 92 124
Distance
from top of
wall mount
to ceiling
(mm)
c505050 50 50 5050
Minimum
Ceiling
Height
(mm)
e 2347 2575 2347 2593 2585 2330 2575
