English
8
Lens shift range
y
Lens shift adjustable range
The adjustable range for lens shift is tabulated below and subject to the conditions listed.
Desk-Front Projection
Normal projection position
Width of projected image
Height of projected image
Height of projected image
Vertical shift
Vertical shift
Vertical shift
Vertical shift
Shift to Left Shift to Right
Max 0.5V
Max 0.5V
1V
1V
1H 0.05H0.05H
Max 0.1V
Ceiling Mount-Front Projection
y
Ceiling Mount Installation
H
C
0.05H
Screen Top
Screen Center
Shift Range
C = Distance from lens to screen
