Q7T4-FP71G LCD Monitor Service Guide
Alignment Procedure
4
Confidential
Write C3 (Reddish) R-Gain Data to EEPROM AA 5C Data cksum
√
Write C3 (Reddish) G-Gain Data to EEPROM AA 5D Data cksum
√
Write C3 (Reddish) B-Gain Data to EEPROM AA 5E Data cksum
√
Write User R-Gain Data to EEPROM AA 6C Data cksum
√
Write User G-Gain Data to EEPROM AA 6D Data cksum
√
Write User B-Gain Data to EEPROM AA 6E Data cksum
√
Write Cx R-Gain Data to EEPROM AA 7C Data cksum
√
Write Cx G-Gain Data to EEPROM AA 7D Data cksum
√
Write Cx B-Gain Data to EEPROM AA 7E Data cksum
√
Reserved for some model have
extra color temperature
Write Contrast to EEPROM AA 92 Data
cksum
√
Write Brightness to EEPROM
AA
93 Data
cksum
√
Write C/T index to EEPROM
AA
94 0~4
cksum
√
1=C1/9300/Bluish,
2=C2/6500/sRGB/,
3=C3/5800/Reddish,
4=User, 5=Cx
Write OSD-Hpos to EEPROM
AA
95 Data
cksum
√
Write OSD-Vpos to EEPROM AA 96 Data
cksum
√
Write Language to EEPROM
AA
97 0~7
cksum
√
0=DE, 1=EN, 2=ES, 3=FR,
4=IT, 5=JA, 6=繁中, 7=簡中
(Also Update MCU RAM)
Write EEPROM OSD Timer
AA
98 Data
cksum
√
Write EEPROM Volume
AA
99 Data
cksum
√
Write EEPROM Gamma index AA 9A Data
cksum
√
For model with Gamma curve
selection function
Write OSD Transparency to EEPROM
AA
9E Data cksum
√
Write OSD Rotation to EEPROM AA 9F Data cksum
√
Read C1 (Bluish) R-Gain data from EEPROM A3 3C XX cksum
√
Read C1 (Bluish) G-Gain data from EEPROM A3 3D XX cksum
√
Read C1 (Bluish) B-Gain data from EEPROM A3 3E XX cksum
√
Read C2 (sRGB) R-Gain data from EEPROM A3 4C XX cksum
√
Read C2 (sRGB) G-Gain data from EEPROM A3 4D XX cksum
√
Read C2 (sRGB) B-Gain data from EEPROM A3 4E XX cksum
√
Read C3 (Reddish) R-Gain data from EEPROM A3 5C XX cksum
√
Read C3 (Reddish) G-Gain data from EEPROM A3 5D XX cksum
√
Read C3 (Reddish) B-Gain data from EEPROM A3 5E XX cksum
√
Read User R-Gain data from EEPROM A3 6C XX cksum
√
Read User G-Gain data from EEPROM A3 6D XX cksum
√
Read User B-Gain data from EEPROM A3 6E XX cksum
√
Read Cx R-Gain data from EEPROM A3 7C XX cksum
√
Read Cx G-Gain data from EEPROM A3 7D XX cksum
√
Read Cx B-Gain data from EEPROM A3 7E XX cksum
√
Reserved for some model have
extra color temperature
Read Contrast from EEPROM A3 92 XX
cksum
√
Read Brightness from EEPROM A3 93 XX
cksum
√
