8
Format Y, Pb, Pr or Y, Cb, Cr
Level / Impedance Y: 1.0Vp-p / 75Ω
Pb/Cb, Pr/Cr: 0.7 ± 0.035Vp-p / 75Ω
HDMI Timing
STANDARD RESOLUTION
V FREQ
Hz
H FREQ
kHz
CLK
MHz
480p 720x480 60 31.46 27
576p 720x576 50 31.25 27
720p 1280x720 50 37.5 74.25
720p 1280x720 60 45.0 74.25
1080i 1920x1080 50 28.12 74.25
1080i 1920x1080 60 33.75 74.25
RGB PC/ HDMI(DVI) Timing
STANDARD RESOLUTION
V FREQ
Hz
H FREQ
kHz
CLK
MHz
VGA 640x480 60 31.47 25.17
VESA
640x480 72 37.86 31.5
VESA
640x480 75 37.5 31.5
VESA
800x600 60 37.88 40
VESA
800x600 72 48.07 50
VESA
800x600 75 46.9 49.5
VESA
1024x768 60 48.36 65.0
VESA
1024x768 70 56.47 75
VESA
1024x768 75 60.02 78.75
VESA
1280x1024 60 64 108
VESA
1280x1024 75 79.97 135
VESA
1440x900 60 55.93 106.5
VESA
1680x1050 59.95 65.29 146.2
Video & S-Video AV Timing
STANDARD RESOLUTION
V FREQ
Hz
H FREQ
kHz
CLK
MHz
NTSC M 525 60 15.734 12.65
PAL(B/G,D/K,I) 625 50 15.625 14.50
SECAM (B/G,D/K,L) 625 50 15.625 14.50
HDTV/Component AV Timing
STANDARD RESOLUTION
V FREQ
Hz
H FREQ
kHz
CLK
MHz
