19 How to assemble your monitor hardware
Turn the stand clockwise so that the arrow on the
bottom of the stand points to RISER UNLOCK
( ). And then detach the base from the stand
().
(For XL2720)
Raise the thumbscrew lid ( ) and release the
thumbscrew as illustrated ( ).
XL2720
Turn the stand counterclockwise until you cannot
go further.
XL2720
2
1
