- 42 -
4
Tear down Al foils
5
Take out the light-wires
from the panel.
6
Disassemble the C/B
7
Disassembled the SHD
shielding : 2/4 screw，and
HDMI screw(the monitor
with DVI have four)
Screw
-driver
