330500 Velomitor Sensor, 330525 Velomitor XA Sensor, 330530 Radiation Resistant Velomitor Sensor Operation Manual
8
(1) Signal input relay module location
(2) Channel A recorder output
(3) Channel B recorder output
(4) Alert relay contacts
(5) Danger relay contacts
(6) Signal input relay module, dual relays
(7) Channel A Velomitor® Sensor
(8) Channel B Velomitor® Sensor
Figure 1-4. 3300 System Connections (3300/55 Monitor)
