Bently Nevada Velomitor Sensor - Environmental; Mechanical

330500 Velomitor Sensor, 330525 Velomitor XA Sensor, 330530 Radiation Resistant Velomitor Sensor Operation Manual
32
5.2.2 Environmental
Operating Temperature
Range
-55
°
C to 121
°
C (-67
°
F to 250
°
F)
Shock Limit 5000 g’s, peak
Humidity Limit 100% Relative (hermetically sealed)
Radiation Dosage 3 Mrads, maximum guarantee,
See White-paper for test summary
5.2.3 Mechanical
Weight 150 g, (5.3 oz), typical
Dimensions See Figures 5-1
Case Material 304L Stainless Steel
Connector 2 pin Mil-C-5015, hermetically sealed,
304 stainless steel shell
Mounting Torque 4.5 N-m (40 in-lbs)
Polarity Pin A goes positive with respect to Pin B when the
sensor case motion is toward the connector.
Note: Operation outside the specified limits will result in false readings or loss of
machine monitoring.
