2. Technical Data
* Depending on which components that are used, dimensions may vary
*I
ØC
A D
H
F
E
Ø B
*G
J
K
L
* The above dimensions are max. measurements. Depending on the
components used, the measurements may vary.
**Min recommended distance to floor.
Burners are intended for use at:
• Hotwater in intermittent operation.
2.1 Dimensions BG 400
• Gas connections 1”
Type
Length of
burner tube
Flange
measure A
BG 400
Standard 1 172 155
Standard 2 272 255
Standard 3 372 355
B C D E F G H I
BG 400
Ø 140 Ø108 100 410 250 *410 192 *506 **200
J K L
BG 400
M10 Ø 175-240 Ø 140
