3.8 Printer
The EXPRESS cannot be used with every printer. For a list of printers which guarantee for
correct performance see our homepage www.gantner.com. If you use another printer than
those mentioned in the list on the homepage, try its performance or contact your delivering
agent.
A printer is connected to the EXPRESS system via the clubPOINT. See picture below.
3.9 clubPOINT
The clubPOINT is equipped with a DB 25 plug used to connect a parallel printer, two DB 9 plugs
used to connect a PC respectively an external clock, three connectors which have the same
function (internally connected) to connect devices like CNN and EXPRESS and a plug for
connecting the power supply unit.
Express
Armature
clubPOINT
clubPOINT
Imprimante
Power Supply
Power Supply
clubPOINT Back View
Printer
