EXPRESS - Fancier
SPECIFICATIONS
HB_EXPRESS_FANCIER-E_13.doc
37
Gantner Pigeon Systems GmbH
11. SPECIFICATIONS
11.1 EXPRESS
Number of pigeons: a maximum of 250
Races: a maximum of 3 at the same time
Voltage: 8 to 20 V DC, regular 12 V DC
or 2 9V batteries
Current consumption: a maximum of 110 mA
RAM memory: CMOS 32 Kbytes
FLASH memory: 160 Kbytes
Program memory: FLASH-EEPROM
Interface: RS 485
Display: LCD offering 2 lines and containing 16 characters plus
3 LEDs next to the LCD
Keyboard: 4 function keys
Clock: CMOS real-time clock,
Quartz clock
Case: plastic ABS
Dimensions (length x width x heigth): 176 x 105.5 x 70 mm
7 x 4.2 x 2.8 inch
Weight (without batteries): approx. 0.34 kg (0.75 lb)
Operating temp.: 0 °C (+32 °F) to +45 °C (+113 °F)
Storage temp.: -25 °C (-13 °F) to + 55 °C (+132 °F)
Protection class IP 50
Service: not required
Battery: 2 batteries at 9 V each
11.2 Antennas
Ring Types: universal ring (VR1)
universal ring (UCR2)
Antenna coil: one per pigeonhole
Pigeonholes: always 1
Number of antennas: a maximum of 7
Reading capacity: a maximum of 7 seconds per antenna
