Remark:
The defaulted temperature of period3 and period4 is the same as
period2. Please change it according to the request.
Period
Week
Weekend
Period Icon
Defaulted Time
Defaulted Temp.
1
2
3
4
5
6
1
2
6:00
8:00
11:30
12:30
17:30
22:00
8:00
23:00
20℃
16℃
16℃
16℃
22℃
22℃
16℃
16℃
Press to switch operation between manual mode and programmable
mode.
7. Advanced Setting
In the state of power-off, press the key and the key for 5 seconds to
enter the advanced option setting.
Press to enter the next option, press “+” or “-” to adjust, and press
to exit.
Sensor error:
Please select the right sensor mode. If select the different mode or there
is error of sensor, Err will display on the LCD screen, the thermostat will
stop heating till the problem is solved.
Display Code
Function
Setting And Options
Factory Defult
1ADJ
Temp.
compensation
-9.9-9.9℃
-2℃
2SEN
Sensor selection
IN: Internal sensor
OUT: Floor sensor
ALL: Both internal
sensor and floor sensor
IN
3LIT
Modify the temp.
limit
5-60℃
35℃
4DIF
Temp. difference
start
0.5-10℃
1℃
5LTP
Antifreeze function
OFF
6PrG
Weekly
programming mode
OFF：Close anti-frozen
ON：Open anti-frozen
2
7rLE
Primary and secondary
reverse selection
00
9HlT
Restore factory
defaults
long press up button to
adjust the display “---”,
press power button to
restore the factory settings
60
8dLy
Passive linkage
output delay time
0-5min
0
0: 7 days programmable
1: 6+1 programmable
2: 5+2 programmable
00: close the main and
auxiliary reversal
02: auxiliary reversal
Set upper temp.
limit
35-95℃
RFAC
-
IX. Installation Instruction
This product is suitable for standard 80*80mm wall box and 60 mm
european round box.
(1)
(2)
(3)
(1)
(4)
1. Connect the power box according to the wiring diagram.
2. Separate the power supply from the control board cable.
3. Screw the power supply into the box of 86.
4. Connect the power board to the board line, and align the buckle at 30
degrees to complete the installation.
X. ATT:
Thank you for buying this product!
Please read this manual for complete instructions on installing and
operating your thermostat. If you require further assistance, please
feel free to contact us.
In the box you will find:
Thermostat
External sensor
User Manual
Screws
Our Service:
We offer the warranty of 24 months from the sales day.
During the warranty, if it is belong to the quality issue, we will fix or
replace them for you by free after test them.
If it is not quality problem or beyond the warranty time, we will
charge for the after-sales service.
TDR89-EP TDR89-WP
√
√
√
√
√
√
√
Model
TDR89-WPB
√
√
√
TDR89 Heating Thermostat
