Music Setup
Background Color
When there is no video image input from
externality, the displayed background color will
change in the following sequence when the
rightward direction key is depressed
：
Blue ► Skyblue ► Green ► Brown
Red ► Olive ► Teal ► Purple
Power Amp IN
Post input selection
Ext.
：
audio signal shall be input from the post input
jack in the rear panel;
Int.
：
used for outputting the general input signal.
Volume Limit set.
Auto volume/volume limit function
When set to ON, the volume will be shifted
automatically to the initial position. When an
external control device is applied to control the
volume, the volume will be limited to its maximum
value.
Initial
：
Volume auto aligning position when turning on
the machine.
Maximum
：
The maximum limit value of volume when
remote control mode enabled.
*The setup of volume beginning position shall
not be higher than the maximum limit value of
volume.
Input Level adj.
Level adjustment for the input audio signal that can
adjust the input signal –6dB ~ +6dB independently.
When returning to the previous page is desired,
firstly move the white-highlighted cursor to the
RETURN position, and then depress the rightward
direction key. * Preset value is 0.
AGC level : 600mV
Automatic Gain Control level
Input signal lower or higher than 600mV will
be modulated to 600mV when enabled; able to
adjust the application setup for the input channels
independently. When returning to the previous
page is desired, fi rstly move the white-highlighted
cursor to the RETURN position, and then depress
the rightward direction key. * Preset value is OFF.
Balance L / R
Balance L/R
To adjust the proportion of music between left and
right; able to adjust the input signal from 0dB to
-30dB (L/R). * Preset value is 0/0.
BBE effect
To adjust the brightness for the sound effect
of music; able to adjust the input signals: high
frequency: from 0 to 12, low frequency: from 0 to
12..
* Preset values are High: 4 and Low: 3.
Bass
To adjust the bass quality for the music; able to
adjust the input signal from -12dB to +12dB.
* Preset value is 0.
Treble
To adjust the treble quality for the music; able to
adjust the input signal from -12dB to +12dB.
* Preset value is 0.
MIC EFFECT MEMORY
Memory selection for the sound effect of
microphone that set up the sound effect of
microphone when turning on the machine.
Available selections are as follows: LAST/EFF1/
EFF2/EFF3/EFF4.
Microphone sound effect setup
EFFECT SETUP
To set up the sound effect of microphone; 4 types
of mode are available for selection and can be set
up thereof singing mode respectively. Depress
rightward pushbutton to enter into the setup mode.
*
This mark represents the effect setup of microphone
currently in use.
E
CHO - DELAY TIME
Set up the delay time; depress the rightward
direction key for increment and the leftward
direction key for decrement; adjustment value: 0
~ 30ms; delay of stereo is adjustable to access
different delay times.
E
CHO - REPEAT Percent
Set up the value; depress the rightward direction
key for increment and the leftward direction key for
decrement; adjustment value: 0 ~ 70.
E
CHO - DEPTH
Microphone effect – depth-adjust the depth percent
of sound, -50% ~ 0 ~ +50%.
R
EVERB - TIME
Set up the reverb time; depress the rightward
direction key for increment and the leftward
direction key for decrement; adjustment value: 0.3
~ 10 Sec.
