14
ADJUSTMENTS
CUTTING HEIGHT ADJUSTMENT
There is approximately 4” of height adjustment.
It is not required to disconnect the spark plug for this
step, since it is done from the driver’s seat.
Adjust the height with the knob for the height control
on the control box.
Dense areas should be cut in two passes.
Push handle down to lock height position in place.
MAXIMUM AND MINIMUM CUTTING HEIGHT
ADJUSTMENT
Use the other adjustment holes (item 1) on the
actuator support. The mower must never come into
contact with the lift stoppers.
TOW HITCH OFFSET
Offset the mower to the opposite side of the
discharge chute of the tow vehicle
It is recommended if the tow vehicle is equipped with
a mid-mount mower to overlap the cut approximately
6”. This may vary depending on mowing terrain,
obstacles, and/or tow vehicle. Always keep safety the
first priority.
Always keep the tow vehicle cutter raised higher than
the mower.
