13
ADJUSTMENTS
FRONT TO BACK ADJUSTMENT
For best cutting results, the cutter deck should be
parallel to the ground. To check parallel adjustment,
measure the distance from the bottom edge of the
deck in both the front and rear of the deck. This
adjustment is best done while the tow vehicle and
mower are attached together.
Adjust as needed by turning the front adjustment
arms (item 1). Turn clockwise to lift the front of the
mower and turn counter clockwise to lower the front
of the mower.
Make sure to have the same adjustment on both
sides of the mower.
LATERAL ADJUSTMENT
The mower must cut evenly from left to right. If this is
not the case, adjust the position of the actuator to
adjust this.
If the mower is lower on the right side than on the left
side, put the actuator on the right side.
If the mower is lower on the left side than on the right
side, put the actuator on the left side.
WARNING
STOP THE ENGINE AND DISCONNECT THE
SPARK PLUG CABLE BEFORE DOING ANY
ADJUSTMENTS ON THE MOWER
