6
ASSEMBLY
IMPORTANT: TORQUE ALL BOLTS ACCORDING
TO TORQUE SPECIFICATION TABLE (SEE TABLE
OF CONTENTS) WHEN STATED: TIGHTEN
FIRMLY. REFER TO PARTS BREAKDOWN
SECTION FOR PART IDENTIFICATION.
Overall view
TOOLS REQUIRED
3 Wrenches 9/16’’, 1/2’’, 3/4’’
1 Ratchet
3 Sockets 9/16’’, 1/2’’, 3/4’’
1 Wrench (for the nuts on the vehicle’s battery
posts)
1 Wooden block
CONVERSION TABLE
1’’ (po, in) 25.4 mm
1’ (pi, ft) 0.3 m
1 psi (lb/in
2
) 6.89 kPa
1 lb 0.45 kg
1 lbf 4.4 N
1 m/h (mi/h) 1.61 km
1 hp (cv) 0.75 kW
GLOSSARY
Quad = V.T.T., A.T.V.
Véhicule tout terrain V.T.T.
All terrain vehicle A.T.V.
Power take-off (P.T.O)
Prise de force (P.D.F)
P.T.O. = P.D.F
