Ethernet Controller EC1000
Energy supply (24 V power supply unit)
Supply voltage
+24 VDC (-20 % / +25 %) SELV max. proportion of a.c. voltage 5 %
Power consumption
typ. 0.3 A, max. 0.3 A with +24 VDC, fuses depending on number of
connected extension modules, max. 2.5 A
Reverse voltage protection
Yes
Potential isolation
No
Bridging in case of power failure
10 ms at < 20.4 VDC (at max. external bus load of 5 V / 2 A) Power
Fail < 19.2 VDC
Ethernet interface
Number / type of interface
1x 10/100 Base T
Connection technology
1x RJ45
EtherCAT interface
Number / type of interface
1x EtherCAT E-bus, lateral 10-pin connection
Connection technology
Series connectors on right-hand side
USB interfaces
Number / type of interface
1 x Host USB Rev. 1.1
Number of mating cycles
max. 1.000
CAN-Bus interfaces
Number / type of interfaces
1x CAN in front (on 2x 5-pin multipoint connector COM / CAN)
Potential isolation
Yes (galvanic isolation)
Transmission rate
ISO 11898 max. 1 Mbit/s
Terminating resistor
external via plug-in connector
Serial interfaces
Number / type of interfaces
1x RS232 3 wire connection to 2x 5-pin multi-point connector in front
panel (RS232+CAN) (RX,TX,GND)
Potential isolation
Yes (galvanic isolation)
Transmission rate
max. Baud rate 115 kBaud
Other functions
Realtime clock
Yes, accumulator battery-buffered (maintenance-free)
SD card
1 SD card slot
Digital input
24 V (-20 % / +25 %)
Slot for left-hand extension module for communication (optional)
Number / type of interfaces
prepared for 1x LAN, 1x CAN, 1x RS485 / 1x RS232
