36
GB
65 80e 90e
When inserting or removing the
bobbin, the needle must be fully raised.
· Open the hinged cover (1).
· Remove the bobbin case by pulling its
latch towards you and pulling it out from
the hook.
· Hold the bobbin case with one hand.
Insert the bobbin so that the thread runs
in a clockwise direction (arrow) (2).
· Pull the thread through the slit and under
the finger (3). spring
· Hold the bobbin case by the hinged
latch (4).
· Insert it into the hook (5). Make sure the
bobbin case finger fits into the notch (6)
at the top of the race.
Attention:
Turn power switch to off (“O”) before
inserting or removing the bobbin.
Inserting bobbinEN
E55-E82e_EN_DE_TR_EL_310309:07_55-90e_EN_ES_FR_PT.qxd 31.3.2009 14:35 Seite 36
