EXPRESS DUAL • ED2000

Ref # Name of Part Qty. Part #

MAINSHAFT MOUNTING AND MAIN MOTOR DRIVE

__________________

1 Side Arm L.H........................................................................... 1 A4122

2 Side Arm R.H. .........................................................................1 A4123

3 Rear Shaft c/w circlips ............................................................ 1 A9108

4 Circlip ......................................................................................2 A5601

5 Main Motor ..............................................................................1 A6040

6 Drive Pulley 60 Hz...................................................................1 A7202

Drive Pulley 50Hz....................................................................1 A7203

7 Taperlock Bush 1108 x 19 .......................................................1 A7301

8 Driven Pulley ...........................................................................1 A7201

9 Taperlock Bush 1610 x 1 ”.................................................... 1 A7303

10 SPZ Drive Belt 60 Hz .............................................................. 1 A7103

SPZ Drive Belt 50Hz ............................................................... 1 A7102

11 Drive Belt Guard......................................................................1 A6334

12 Mainshaft................................................................................. 1 A9068

13 Grinding Stone ........................................................................1 A6505

14 Sleeve...................................................................................... 1 A9116

15 Nut ........................................................................................... 1 A9095

Sleeve & Nut assembly ...........................................................1 A9506

16 Mainshaft Bearing ................................................................... 2 A7721

17 Oilite Bush 1 ” bore............................................................... 2 A7701

18 Plastic Washer......................................................................... 2 A6759

19 Hex.Nut M12............................................................................4 A5506

20 Washer M12 ............................................................................8 A5315

21 Hex. Head Bolt M12 x 45......................................................... 4 A5714

22 Hex. Head Bolt M8 x 25 ..........................................................4 A5216

23 Washer M8 ..............................................................................4 A5321

24 Motor Bolt Retaining Plate ......................................................2 A4078

25 Hex. Set Screw M10 x 70 ........................................................2 A5711

26 Locknut M10 ............................................................................2 A5503

27 Button Head Socket Screw M5 x 10 ....................................... 2 A5129

9. Parts List
