Bernhard EXPRESS DUAL ED2000 - Identification of Pictograms

EXPRESS DUAL • ED2000
© Bernhard and Company Limited
4
EXPRESS DUAL • ED2000
© Bernhard and Company Limited
5
BEWARE! HIGH VOLTAGE
1. Identication of Pictograms
MAXIMUM LIFT PLATFORM
LOAD - 250 KG (550 LBS)
BEWARE!
TRAPPING FEET OR OTHER OBJECTS
WHEN LOWERING LIFT PLATFORM
MAXIMUM GRINDSTONE
DIAMETER 150mm
MAXIMUM SPEED 2200 Rev/Min
BEWARE!
MOVING GRINDSTONE AND SHAFT
REEL ROTATING AT BETWEEN
147 AND 255 Rev/Min
TOTAL WEIGHT OF MACHINE (KG)
