Ref # Name of Part Qty. Part #
TRAVERSE ASSEMBLY
__________________________________________________
1 Forkdriver (only) ......................................................................1 A9512
Forkdriver c/w bushings & seals .............................................1 A9505
2 Shaft for Forkdriver .................................................................1 A9050
3 Ball Bushing for Forkdriver...................................................... 2 A7706
4 Dust Seals for Forkdriver ........................................................2 A7707
5 Socket Screw M6 x 6............................................................... 2 A5156
6 Shaft for Pick up ...................................................................... 1 A9183
7 Traverse Pick Up .....................................................................1 A9518
8 Ball Bushing for Trav. Pick Up.................................................2 A7702
9 Dust Seal for Trav. Pick Up .....................................................2 A7703
10 Hex. Head Screw M12 x 25..................................................... 2 A5712
11 Washer M12 ............................................................................2 A5315
12 Engagement Screw .................................................................1 A6112
13 Lobed Knob M12 .....................................................................1 A6102
14 Reversing Bar..........................................................................1 A4111
15 Reversing Bar Stop .................................................................2 A4113
16 Cross Knob M8 x 15................................................................2 A6131
17 Microswitch.............................................................................. 1 A8111
18 Housing for Microswitch .........................................................1 A8113
19 Guard for Microswitch ............................................................. 1 A6382
20 Screw 2BA x 1 ”.................................................................... 2 A5404
21 Traverse Motor .......................................................................1 A6022
22 Idler Sprocket .......................................................................... 1 A7609
23 Oilite Bush for Sprocket ..........................................................1 A7704
24 Spindle for Idler Sprocket........................................................1 A9057
25 Drive Sprocket.........................................................................1 A7603
26 Traverse Chain ........................................................................1 A7406
27 Link for Traverse Chain ........................................................... 1 A7502
28 Circlip ” .................................................................................1 A5602
29 Hex. Nut M10...........................................................................1 A5503
30 Socket Screw ..........................................................................1
31 Hex Head Screw M6 x 18........................................................ 4 A5719
32 Washer M6 .............................................................................. 4 A5320
33 Capacitor 3uf for Trav Motor ..................................................1 A8148
34 Friction Spring for Rev Bar...................................................... 1 A6746
35 Socket Screw ”Whit x ”...................................................... 1 A5101
9. Parts List
