76
Technical data
Stitch types
Top & bottom cover stitch: 3 needles 1 wiper 1 looper 5 mm
2 needles 1 wiper 1 looper 5 mm
2 needles 1 wiper 1 looper 2.5 mm
Cover stitch: 3 needles 1 looper 5 mm
2 needles 1 looper 5 mm
2 needles 1 looper 2.5 mm
Chain stitch: 1 needle 1 looper
4 thread overlock with integrated safety seam: 2 needles 2 loopers
3 thread super stretch: 2 needles 1 looper
3 thread overlock, flatlock, roll hem: 1 needle 2 loopers
2 thread overlock, flatlock, roll hem: 1 needle 1 looper
Seam width: 2.5 mm 2 needle cover stitch
5 mm 3 needle cover stitch
2 needle cover stitch
3–7 mm 2/3 thread overlock
5–7 mm 4 thread overlock/3 thread overlock
Stitch length: 1–4 mm
Differential feed: Pushing effect: N–2
Stretching effect: 0.7–N
Presser foot: Standard foot (swing-out), snap-on sole
Cover stitch foot (compensating foot), snap-on sole
Presser foot lifter: Two-step. Max. lift 7 mm.
Integrated accessories: Roll hemmer, tape guide
Handwheel: Rotates forwards (counter-clockwise)
Needle system: 130/705H
(JLx2 can be used if necessary for cover/chain stitch)
Electronic needle stop: Cover stitch/top & bottom Position F,H generally down
Chain stitch Position G, generally down
Overlock stitches Positions A–E, generally up
Sewing speed: Max. 1500 s.p.m. for overlock stitches (Pos. A–E)
Max. 800 s.p.m. for cover stitch (Pos. F)
Max. 800 s.p.m. for chain stitch (Pos. G)
Max. 500 s.p.m. for top&bottom cover stitch (Pos. H)
Safety: Micro safety switches
LED safety control lamps
Weight: 2500DCET 8.8 kg
Dimensions: 335 W x 295 D x 340 H mm
Foot control: Model Nr. YC-425
We reserve the right to make changes in the interests of technical progress.
