11General operating instructions
Embroidery functions
Starting embroidery with the quick
reverse button on the head frame
· start by pressing the quick reverse
button on the frame head (approx.
3 seconds will elapse before the
audio signal stops)
· the sewing computer does about
6 stitches, then stops, so that you
can cut the thread tails
Layout 1 and layout 2
·press “layout 1” or “layout 2” to
switch between the layout screens
· it is not possible to embroider in the
layout screens
Menu
· found on the sewing and layout 1
or layout 2 screens
· touch to select
· either the embroidery module or
card stitch summary appears
Multi-color motifs*
· found on the sewing screen
· the total number of colors appears
small on the right
· the number of the color to be
embroidered appears large on the
left
· touch the right or left arrow to
change the color
· the sections for the selected color
are highlighted in black on the
embroidery screen, the remainder
of the motif appears gray
Manual adjustment of color
sequence*
· on rescrolling through the color
sequence, the end of the preceding
color appears
· the large number on the left in the
rectangle then changes from black
to gray
Single/multi color motif/
embroidery time*
· found on the sewing screen
· touch the symbol
· white background = multi color
motifs, each color is embroidered
separately
· the embroidery time for the actual
color is shown
· gray background – single color
motifs
· the complete (remaining)
embroidery time is shown in the left
section of the screen
Embroidery sequence*
· found on the sewing screen
· touch to select
· screen shows thread breakage
symbol with arrows
Embroidery sequence control
(on thread breakage)
· touch the right or left arrow
· the embroidery sequence can be
checked in stages
· if the thread has broken, touch one
of the arrows
· the needle follows the sequence in
small forward or reverse steps
(left arrow – reverse, right arrow –
forwards)
Embroidery speed
· touch “M
–”= proportional
reduction of embroidery speed
· touch “M
+”= proportional increase
of embroidery speed
· the percentage speed (%) is shown
in symbol “M
+”
· the embroidery time always relates
to 100% speed
* see message P.16 “No embroidery hoop attached” and the related response
